Gethray GT-C3204 Solvent Printer – Overview
The Gethray GT-C3204 Solvent Printer (GT3204Si) belongs to Gethray’s GT platform – the chassis family that also carries their UV and multi-ink machines. That matters: you get the 200×100×7 mm square-tube main girder, aluminium carriage beam, THK linear guide way, 3-level high-precision pinch rollers, 195 mm print bed with adjustable vacuum and LED bed lighting, automatic capping & wiping and an anti-collision carriage system. As the solvent configuration with four Konica heads, it is a factory-honest production machine for flex, self-adhesive vinyl, one-way vision and coated banner work.
The Gethray GTC3204 runs all day on flex banners, vinyl hoardings, self-adhesive vinyl, one-way vision film, mesh, backlit flex, coated banner, PVC and PP media, canvas and fabric backdrops. Solvent and eco-solvent prints are waterproof and UV-resistant for long outdoor life, and the machine’s service ecosystem is supported across India.
Key Features
- 4 × Konica solvent heads – balanced speed/quality production
- 200×100×7 mm square-tube girder + aluminium beam – rigid GT chassis
- THK linear guide way with long-life block
- Automatic capping & wiping + anti-collision carriage system
- 3-level precision pinch rollers + adjustable vacuum bed
- Italy Megadyne belt, Germany Igus drag chain & power cable, fibre data cable
- 180 dpi (9730) encoder; manual carriage lifting for thick media
Print Speed (4-head Konica 512i configuration (BYHX platform))
| Print Mode | Output Speed |
|---|---|
| 2 pass (480×360 dpi) | up to 240 m²/h |
| 3 pass (480×540 dpi) | up to 160 m²/h |
| 4 pass (480×720 dpi) | up to 125 m²/h |
Speeds are manufacturer test-condition figures; real output varies with media, RIP settings and feather mode.
Technical Specifications
| Model | Gethray GT-C3204 (GT3204Si) |
| Print Head | 4 × Konica solvent heads |
| Max. Print Width | 3.2 m |
| Ink Type | Solvent ink (platform supports eco-solvent / water-based / sublimation variants) |
| Colours | CMYK (CMYK×2 / W+CMYK / CMYK+W platform options) |
| Media (solvent) | Flex, self-adhesive vinyl, one-way vision, coated banner |
| Media Transmission | Multi-function double industry motor |
| Main Girder | 200×100×7 mm square tube; Y-axis 20 mm |
| Guide Way | THK linear guide way |
| Printing Bed | 195 mm wide bed, adjustable vacuum suction, LED bed lighting |
| Capping / Safety | Automatic capping & wiping; anti-collision system |
| RIP Software | MainTop 6.1 / PhotoPrint |
| Interface | LAN |
| Power Supply | AC 220 V, 50/60 Hz · system 1800 W + heater 4000 W |
| Machine Size | 4580 × 980 × 1550 mm (L×W×H) |
| Weight | N.W. approx. 1000 kg · G.W. 1220 kg |
| Operating System | Windows 10, 64-bit |
| Operating Environment | 15–30 °C, 40–65% RH |
Applications
Typical work: flex banners, vinyl hoardings, self-adhesive vinyl, one-way vision film, mesh, backlit flex, coated banner, PVC and PP media, canvas and fabric backdrops. The machine is at home in flex printing units, signage fabricators, advertising agencies and in-house brand print rooms.
Why Buy from Unified Engineering Dynamics?
- Authorized Grando supply in India – genuine machines with official configuration, not grey-market refits.
- Complete installation & training – on-site setup, RIP software installation, media profiling and operator training included.
- After-sales support – Indian service engineers, genuine spare parts and print heads in stock, remote diagnostics.
- Consumables supply – matched eco-solvent inks, cleaning solution and spares available from our Printing Inks and Printer Spare Parts range.
Need the latest price, a demo print or an EMI quotation? Contact our team today – we reply within one working day with a detailed offer including installation and ink start-up kit options.
