eRICK ER-ECO 1801E Eco Solvent Printer (1× Epson i3200-E1, 1.8m) – Overview
The eRICK ER-ECO 1801E is the entry point into genuine Epson i3200 eco-solvent printing: a 1.8-metre roll-to-roll machine running a single Epson i3200-E1 PrecisionCore head (i1600-E1 available for tighter budgets) at up to 25 m²/h in 4-pass production. The ERICK E-series body packs an integrated power box, servo-motor media drive, platform suction to hold media flat, a 2.5L positive-pressure bulk ink system with no cartridges to swap, and a front-panel temperature controller driving the heater and fan drying array. Anti-collision sensors protect the head, and Maintop or PhotoPrint RIP support with LAN connectivity slots straight into any Windows print room.
The ER-ECO-1801E prints daily-shop work across self-adhesive vinyl stickers & decals, vehicle wraps, flex & PVC banners, backlit film & backlit boards, one-way vision film, window & glass graphics, wallpaper & wall wraps, PP paper / photo posters, canvas prints and exhibition graphics. Eco-solvent output is waterproof, scratch-tolerant and outdoor-durable without lamination for short-term signage, and fully lamination-ready for vehicle and long-life graphics.
Key Features
- 1 × Epson i3200-E1 PrecisionCore head, 3200 nozzles (i1600-E1 option)
- Up to 25 m²/h (≈269 sqft/hr) 4-pass production on i3200-E1
- Standard resolution 1440×2880 dpi – true photographic quality
- 2.5L bulk ink tank with positive pressure continuous supply
- Servo motor drive + platform suction for accurate, drift-free feeding
- Integrated power box & tidy cable management for Asia-class reliability
- Temperature controller with heater fan array – prints dry instantly
- Anti-collision head protection; Maintop / PhotoPrint RIP over LAN
Print Speed (ER-ECO 1801E · official ERICK/Aily data)
| Print Mode | Output Speed |
|---|---|
| i3200-E1 · 4 pass | 25 m²/h (≈269 sqft/hr) |
| i3200-E1 · 6 pass | 20 m²/h (≈215 sqft/hr) |
| i3200-E1 · 8 pass | 17 m²/h (≈183 sqft/hr) |
| i1600-E1 · 4 pass | 13 m²/h (≈140 sqft/hr) |
| i1600-E1 · 6 pass | 10 m²/h (≈108 sqft/hr) |
| i1600-E1 · 8 pass | 8 m²/h (≈86 sqft/hr) |
Speeds are manufacturer test-condition figures; real output varies with media, RIP settings and pass count. Rows marked (class) are platform-class figures confirmed at order time.
Technical Specifications
| Model | eRICK ER-ECO 1801E |
| Print Head | 1 × Epson i3200-E1 (i1600-E1 option), 3200/1600 nozzles |
| Max Print Size | 70 in (1800 mm) |
| Printing Resolution | Standard 1440×2880 dpi |
| Printing Quality | True photographic quality |
| Ink | Eco solvent ink, CMYK; 2.5L tank, positive pressure continuous supply |
| Machine Functions | Anti-collision, platform suction system, white ink stirring system |
| Max Media Weight / Head Height | 30 kg / 1–5 mm |
| Materials | PP paper, backlit film, wallpaper, vinyl, one-way vision, flex banner |
| RIP Software | Maintop / PhotoPrint; TIFF, JPEG, EPS, PDF |
| Interface / OS | LAN; Windows 7 / Windows 10 |
| Power | AC 220V 50/60Hz – machine 1800W + heating 4000W |
| Media Feeding | Manual feed, roll-to-roll |
| Machine Size / Weight | 2930 × 730 × 1400(H) mm / 250 kg |
| Package | 3100 × 740 × 730(H) mm / 310 kg, wooden case |
| Working Environment | 15–30 °C |
Applications
Typical work: self-adhesive vinyl stickers & decals, vehicle wraps, flex & PVC banners, backlit film & backlit boards, one-way vision film, window & glass graphics, wallpaper & wall wraps, PP paper / photo posters, canvas prints and exhibition graphics. The machine is at home in signage shops, flex printing units, advertising agencies, event & exhibition graphics workshops and vehicle-wrap studios.
Why Buy from Unified Engineering Dynamics?
- Genuine eRICK machines – original ERICK eco-solvent printers (Aily Group factory configuration), supplied with full warranty and genuine Epson print heads.
- Complete installation & training – on-site setup, RIP software installation, media profiling and operator training included.
- After-sales support – trained service engineers, genuine Epson print heads and spare parts in stock, remote diagnostics.
- Consumables supply – matched flex solvent inks, cleaning solution and spares available from our Printing Inks and Printer Spare Parts range.
Need the latest price, a demo print or an EMI quotation? Contact our team today – we reply within one working day with a detailed offer including installation and ink start-up kit options.
